DE AURA HVLS Ceiling Fan PROFAN P10 3 M/10Ft 6 Blade 400M3/MIN 240V~50Hz
DE AURA HVLS Ceiling Fan PROFAN P10 3 M/10Ft 6 Blade 400M3/MIN 240V~50Hz
Product Details:
- Designed best for users safety and comfort.
- Custom mounting systems for customers.
- Fan can be mounted to different construction profiles.
- Safety Cable secures the fan to the mounting structure.
- Fans are tested and simulated for best results.
Benefits of Ceiling Fans:
- Require lower cost for investment, installation and maintenance than traditional cooling methods.
- Cut energy consumption for heating. Provide eco-friendly and economic solutions.
- Assist in the removal of contaminant and heat.
- Help reduce condensation on floors and equipments.
- Work coordinated with high velocity fans and other air conditioning systems.
- Offer multi-fan control and adjustable fan speed.
- Offer silent operation. Supply winter destratification and summer cooling.
Model Features:
| Fan Diameter | Number of Wings | Supply Voltage | Power (Kw) | RPM | Flow (m³/h) | Noise (db) | Weight (kg) | Range (m²) | |
|---|---|---|---|---|---|---|---|---|---|
| P8 | 2450 | 6 | 220-230 | 0,37 | 100 | 46200 | <55 | 88 | 280 |
| P10 | 3050 | 6 | 220-230 | 0,37 | 100 | 89000 | <55 | 102 | 375 |
| P12 | 3660 | 6 | 220-230 | 0,37 | 90 | 110000 | <55 | 109 | 430 |
| P14 | 4270 | 6 | 220-230 | 0,63 | 100 | 245000 | <55 | 116 | 680 |
| P16 | 4880 | 6 | 220-230 | 0,75 | 60 | 273000 | <55 | 136 | 650 |
| P18 | 5500 | 6 | 220-230 | 1,04 | 70 | 335000 | <55 | 157 | 735 |
| P20 | 6100 | 6 | 220-230 | 1,09 | 60 | 392000 | <55 | 145 | 805 |
| P22 | 6700 | 6 | 220-230 | 1,09 | 55 | 476000 | <55 | 169 | 1018 |
| P24 | 7300 | 6 | 220-230 | 1,09 | 55 | 616000 | <55 | 176 | 1256 |
